Chapter 7: Intelligence and Hunting on the Dark Web#

The previous chapters have covered four darknets in detail and their similarities and differences. The last chapter also gave a good overview of the contents to expect. Now that you have a much better understanding of what the Dark Web is and what information it contains, it is interesting to study how to extract and organize the information that is relevant to you, mainly if you are in the cybersecurity domain (e.g., Threat Intelligence Analyst, Threat Hunter) or in a law enforcement administration (e.g., Cybercrime Investigator, Cybercrime Intelligence Officer, etc.) as the Dark Web is an excellent source of threat intelligence and threat hunting.

Introduction#

Why Does Monitoring the Dark Web Matter?#

You may have different objectives:

Create your search engine: This involves collecting as many links as possible and parsing all pages to index content and return relevant pages for the search criteria.
Threat intelligence: Monitor a list of predefined pages, boards, forums, or markets against a list of keywords (e.g., your company name, your domain, and subdomains, IP addresses, hostnames, people’s names, vulnerabilities, etc.) to alert when keywords match.
Metadata collection: Browse pages to collect metadata and make statistics or find interesting items (IP addresses, keys, email addresses, etc.), often based on specific regular expressions.
Investigation: Investigators might want to monitor specific places (e.g., darknet markets, blockchain tracking). This investigation may also involve correlating information from other sources found on the Surface Web and Deep Web.

As far as threat intelligence is concerned, the reasons that generally motivate companies to monitor the Dark Web are pretty obvious:

Targeted attacks: Threat actors sometimes discuss targeted attacks against specific individuals and organizations on Dark Web forums. These conversations can provide valuable insight into potential attack vectors and inform your risk management team.
Leaked data: stolen and leaked credentials are available for sale on Dark Web forums and markets. Credentials are extremely valuable, allowing cybercriminals to use them to carry out brute force or identity theft attacks.
Vulnerability information: Zero-day vulnerabilities are discussed or sold on the Dark Web. As no security patch is available yet for these flaws, threat actors can leverage them to attack companies.

¹https://www.darkreading.com/threat-intelligence/hunting-insider-threats-on-the-dark-web

Insider Threats: Insider threats are a serious and growing problem ¹ ¹https://www.darkreading.com/threat-intelligence/hunting-insider-threats-on-the-dark-web. The Dark Web is a rich source of information about insider threats and insiders looking to sell your company’s trade secrets, intellectual property, or sensitive data.

Definition of the Scope#

Suppose your objective is to build your threat intelligence monitoring service. In that case, you should not limit yourself to the information found on the Dark Web and extend it to social media, boards, and forums on the Surface Web and the Deep Web. There are good lists available on the Internet, like Link-Base ² ²https://link-base.ms.

That said, because this book is about the Dark Web, we will limit ourselves to the information available on the Dark Web, specifically Tor and I2P, which are the most relevant references for this consideration.

Steps for a Successful Monitoring#

Depending on your project, sources to be considered, information to be extracted, and the way data will be processed will likely differ, but the workflow should remain the same, with the following steps:

Sources collection > Crawling and extraction > Save to Database > Reporting

The following sections will provide some hints on how to successfully run these steps, with links to resources and tools.

Extracting Information#

Once you’ve identified the relevant sources for your project and your objective, you will likely need to crawl pages and extract partial to complete content. This section gives some tools (mainly for Tor) that can help to:

return a list of links based on keywords,
index text contained on pages,
extract screenshots, titles, content, observables (IP addresses, domains, email addresses, CVE, file hashes, crypto keys, etc.),
save content to a database.

Torsocks, Torify, and Proxychains#

To parse an Onion Service with the command line, you can use curl with the --socks5-hostname option, torsocks, torify (a wrapper for torsocks), or proxychains (use proxychains4), as shown in the examples below:

$ URL="http://tor66sewebgixwhcqfnp5inzp5x5uohhdy3kvtnyfxc2e5mxiuh34iid.onion/fresh"
$ curl -s --socks5-hostname 127.0.0.1:9050 $URL
$ torsocks curl -s $URL
$ torify curl -s $URL
$ proxychains curl -s $URL

TorBot#

TorBot ²¹ ²¹DedSecInside/TorBot extracts information (page title, emails, links, …) from a list of Onion links. The following commands show how to install TorBot.

$ git clone https://github.com/DedSecInside/TorBot.git
$ cd TorBot/
$ python3 -m venv torbot_venv
$ source torbot_venv/bin/activate
(torbot_venv) $ pip install -r requirements.txt
(torbot_venv) $ pip install -e .

Once done, check that you have no errors while running the below command:

(torbot_venv) $ ./main.py --help

Below is an output example of TorBot:

TorCrawl#

TorCrawl ²² ²²MikeMeliz/TorCrawl.py is a Python script that crawls and extracts links from web pages (Surface Web pages or Onion Services) through Tor.

For example, you can run the below command to extract links on a page.

$ python3 torcrawl.py -u https://dark.fail -c -d 1
## Crawler started from https://dark.fail with 1 depth crawl, and 0 second(s) delay.
## Step 1 completed with: 42 result(s)
## File created on /data/TorCrawl.py/output/dark.fail/241114_links.txt

Links are saved in the output directory.

$ cat output/dark.fail/241114_ext-links.txt
https://mastodon.social/@darkdotfail
https://nitter.dark.fail/darkdotfail
https://www.torproject.org
https://supporters.eff.org/

$ cat output/dark.fail/241114_links.txt | head
https://dark.fail/nyt
https://dark.fail/pgp.txt
https://dark.fail/torbox
https://dark.fail/mirrors.txt
https://dark.fail/tlc
https://dark.fail/cryptostorm
https://dark.fail/openpgp
https://dark.fail/tor
https://dark.fail/cryptostamps
https://dark.fail/facebook

TorCrawl only detects links by extracting the href value of the <a> HTML tags. If a page contains Onion Services as text that are not HTML links, they won’t be listed:

Fig. 319 Onion services not natively identified by TorCrawl.#

To extract them, we can use TorCrawl without the -c argument and filter the output to extract the onion links as follows:

$ python3 torcrawl.py -u https://dark.fail | grep -Eo "https?://[a-zA-Z0-9]{56}.onion" | head
http://dreadytofatroptsdj6io7l3xptbet6onoyno2yv7jicoxknyazubrad.onion
http://g66ol3eb5ujdckzqqfmjsbpdjufmjd5nsgdipvxmsh7rckzlhywlzlqd.onion
http://recon222tttn4ob7ujdhbn3s4gjre7netvzybuvbq2bcqwltkiqinhad.onion
http://libreeunomyly6ot7kspglmbd5cvlkogib6rozy43r2glatc6rmwauqd.onion
http://4pt4axjgzmm4ibmxplfiuvopxzf775e5bqseyllafcecryfthdupjwyd.onion
http://exploitivzcm5dawzhe6c32bbylyggbjvh5dyvsvb5lkuz5ptmunkmqd.onion
http://uicrmrl3i4r66c4fx4l5gv5hdb6jrzy72bitrk25w5dhv5o6sxmajxqd.onion
http://lgh3eosuqrrtvwx3s4nurujcqrm53ba5vqsbim5k5ntdpo33qkl7buyd.onion
http://wmj5kiic7b6kjplpbvwadnht2nh2qnkbnqtcv3dyvpqtz7ssbssftxid.onion
http://archiveiya74codqgiixo33q62qlrqtkgmcitqx5u2oeqnmn5bpcbiyd.onion

VigilantOnion#

VigilantOnion ²³ ²³andreyglauzer/VigilantOnion is a tool that parses Onion Service links collected from services available on the Surface Web (Pastebin, Reddit, Gist, etc.).

To install VigilantOnion, it is recommended first to create a virtual environment where Python dependencies will be installed. We assume you already have a /data/venv/ directory with correct permissions.

$ sudo apt install python3-venv
$ python3 -m venv /data/venv/vigilantonion

Now, activate the virtual environment and download VigilantOnion:

$ source /data/venv/vigilantonion/bin/activate
(vigilantonion) $ cd /data/
(vigilantonion) $ git clone https://github.com/andreyglauzer/VigilantOnion.git
(vigilantonion) $ cd VigilantOnion/

Update some outdated Python dependencies to avoid build errors:

(vigilantonion) $ sed -i "s/beautifulsoup/beautifulsoup4/" requirements.txt
(vigilantonion) $ sed -i "s/PyYAML==5.4/PyYAML/" requirements.txt

Now, proceed with the installation:

(vigilantonion) $ pip install -U pip
(vigilantonion) $ pip install -r requirements.txt
(vigilantonion) $ pip install pysocks
(vigilantonion) $ pip install yara-python
(vigilantonion) $ sudo apt install libpcre3

VigilantOnion should now be installed. You can check that it runs without errors:

(vigilantonion) $ python3 observer.py -h

Now, you’ll need to install your own data lake (Splunk or Elasticsearch) and configure VigilantOnion to send the syslog logs to it. We’ll assume we have a Splunk server installed on 192.168.1.94 and configured a listening port running on port 515/udp. This can be applied as follows in the configuration file (./config/config.yml):

Listing 12 ./config/config.yml (extract)#

sendlog: True
logport: 515
logip: "192.168.1.94"

Now, we should be able to use VigilantOnion. Let’s test a single URL:

(vigilantonion) $ python3 observer.py --config config/config.yml --crawler --url "darkfailenbsdla5mal2mxn2uz66od5vtzd5qozslagrfzachha3f3id.onion"
2024-11-15 11:49:08.205 INFO observer - start: Starting the Crawler process.
2024-11-15 11:49:08.212 INFO crawler - start: Starting the process Crawler at url darkfailenbsdla5mal2mxn2uz66od5vtzd5qozslagrfzachha3f3id.onion.
2024-11-15 11:49:10.274 INFO crawler - crawler: Updating url status darkfailenbsdla5mal2mxn2uz66od5vtzd5qozslagrfzachha3f3id.onion for 200.
'Hacking',dark.fail: Which Tor sites are online?,'[Hacking, Shop]'
2024-11-15 11:49:20.342 INFO crawler - start: Getting more urls from the address darkfailenbsdla5mal2mxn2uz66od5vtzd5qozslagrfzachha3f3id.onion.
2024-11-15 11:49:20.343 INFO crawler - more_urls: Searching for new urls in: darkfailenbsdla5mal2mxn2uz66od5vtzd5qozslagrfzachha3f3id.onion
2024-11-15 11:49:21.373 INFO crawler - crawler: Updating url status darkfailenbsdla5mal2mxn2uz66od5vtzd5qozslagrfzachha3f3id.onion/pgp for 200.
'Hacking',Verify a PGP signature with dark.fails PGP Tool,'[Hacking]'
2024-11-15 11:49:31.841 INFO crawler - crawler: Updating url status darkfailenbsdla5mal2mxn2uz66od5vtzd5qozslagrfzachha3f3id.onion/dread for 200.
'Hacking',Is Dread online on the darknet?,'[Hacking]'
2024-11-15 11:49:42.269 INFO crawler - crawler: Updating url status darkfailenbsdla5mal2mxn2uz66od5vtzd5qozslagrfzachha3f3id.onion/recon for 200.
'no_match',Is Recon online on the darknet?,'no_match'
[REDACTED]

The output sent to Splunk is a JSON object that looks as follows:

{
        lastscan: "2024-11-15",
        id: 13380,
        type: "URI",
        url: "darkfailenbsdla5mal2mxn2uz66od5vtzd5qozslagrfzachha3f3id.onion/privacy",
        title: "Privacy Policy of Dark.fail",
        baseurl: "darkfailenbsdla5mal2mxn2uz66od5vtzd5qozslagrfzachha3f3id.onion",
        status: "Online",
        count_status: 0,
        source: "Script",
        categorie: [
                {
                        full_categorie: [
                                "Hacking",
                                "Shop"
                        ],
                        score_categorie: 60
                }
        ],
        keywords: [
                {
                        full_keywords: [
                                "email_filter"
                        ],
                        score_keywords: 10
                }
        ],
        discovery_date: "2024-11-15 11:58"
}

In Splunk, you can build a dashboard as follows:

Fig. 320 Splunk dashboard based on VigilantOnion data.#

You can also collect Onion Service links from services available on the Surface Web and then parse the links:

(vigilantonion) $ python3 observer.py --config config/config.yml --search -e "gist,reddit,cybersecuritynews,discoverdarkwebservice"
(vigilantonion) $ python3 observer.py --config config/config.yml --crawler

OnionScan (Prerequisite for OnionIngestor)#

OnionScan, which we will install as a prerequisite for OnionIngestor, is a tool that reports misconfigurations and vulnerabilities on Onion Services. Findings include Apache2 “mod_status” leak, open directories, EXIF tags, server fingerprint, and PGP identities.

To avoid the “package crypto/ecdh is not in GOROOT” error due to the current version of “Go” in Debian packages, we’ll start by installing the latest version of “Go.” Go to https://go.dev/dl/ and get the latest version for your environment (e.g., “go1.23.3.linux-amd64.tar.gz”).

$ cd /data/tmp/
$ wget https://go.dev/dl/go1.23.3.linux-amd64.tar.gz
$ tar xzf go1.23.3.linux-amd64.tar.gz
$ sudo mv go/ /usr/local/

Now, set environment variables:

$ cat >> ~/.bashrc << EOF
export GOROOT=/usr/local/go
export GOPATH=\$HOME/go
export PATH=\$GOPATH/bin:\$GOROOT/bin:\$PATH
EOF
$ . ~/.bashrc

The below command will download OnionScan to the ~/go directory.

$ cd /data/
$ go mod init onionscan
$ go get github.com/s-rah/onionscan

Install dependencies:

$ go get github.com/HouzuoGuo/tiedot
$ go get golang.org/x/crypto/openpgp
$ go get golang.org/x/net/proxy
$ go get golang.org/x/net/html
$ go get github.com/rwcarlsen/goexif/exif
$ go get github.com/rwcarlsen/goexif/tiff

By default, OnionScan still uses the Tor version 2 URL format. To include the Tor v3 URL format, modify the validation.go file as follows.

$ cd ~/go/pkg/mod/github.com/s-rah/onionscan@v0.0.0-20170225171031-da42865bb5b1/utils/
$ sudo sed -i "s/\[a-z2-7\]{16}/\[a-z2-7\]{16,56}/" validation.go

Install OnionScan:

$ cd ~/go/pkg/mod/
$ go install github.com/s-rah/onionscan@v0.0.0-201702251
  71031-da42865bb5b1
go: finding module for package github.com/rwcarlsen/goexif/exif
go: finding module for package golang.org/x/crypto/ssh/terminal
go: finding module for package github.com/rwcarlsen/goexif/tiff
go: finding module for package golang.org/x/crypto/openpgp
go: finding module for package golang.org/x/net/html
go: finding module for package golang.org/x/net/proxy
go: finding module for package github.com/HouzuoGuo/tiedot/db
go: finding module for package golang.org/x/crypto/ssh
go: found golang.org/x/crypto/ssh/terminal in golang.org/x/crypto v0.29.0
go: found github.com/rwcarlsen/goexif/exif in github.com/rwcarlsen/goexif v0.0.0   -20190401172101-9e8deecbddbd
go: found github.com/rwcarlsen/goexif/tiff in github.com/rwcarlsen/goexif v0.0.0   -20190401172101-9e8deecbddbd
go: found golang.org/x/crypto/openpgp in golang.org/x/crypto v0.29.0
go: found golang.org/x/net/html in golang.org/x/net v0.31.0
go: found golang.org/x/net/proxy in golang.org/x/net v0.31.0
go: found github.com/HouzuoGuo/tiedot/db in github.com/HouzuoGuo/tiedot v0.0.0-2   0210905174726-ae1e16866d06
go: found golang.org/x/crypto/ssh in golang.org/x/crypto v0.29.0

And then test the binary in $GOPATH/bin/onionscan as shown below.

$ ~/go/bin/onionscan --help

OnionIngestor#

OnionIngestor ²⁴ ²⁴danieleperera/OnionIngestor is an extendable tool to collect, crawl, and monitor Onion Services on Tor and index collected information on Elasticsearch. Note that the project has been archived on GitHub, but it is detailed in this book because it can still be an interesting reference for your project. We’ll assume that you already have running instances of Elasticsearch and Kibana, as the installation and configuration of these packages are not covered in this book.

The below commands show how to install OnionIngestor in a virtual environment:

$ python3 -m venv /data/venv/onioningestor
$ source /data/venv/onioningestor/bin/activate
(onioningestor) $ cd /data
(onioningestor) $ git clone https://github.com/danieleperera/OnionIngestor.git
(onioningestor) $ cd OnionIngestor/
(onioningestor) $ sudo apt update && sudo apt install python3-dev libxml2-dev libxslt1-dev
(onioningestor) $ pip install -U pip
(onioningestor) $ pip install -r requirements/prod.txt

Note

At this stage, the latest command failed because of missing dependencies. I solved the issue by installing the latest LXML package, removing it from the requirements, and rerunning the installation command:

(onioningestor) $ pip install lxml
(onioningestor) $ sed -i "s/^lxml/#lxml/" requirements/prod.txt
(onioningestor) $ pip install -r requirements/prod.txt

And now, install OnionIngestor:

(onioningestor) $ python3 setup.py install

Check that you have no errors with the below command.

(onioningestor) $ python3 -m onioningestor --help

The connection string for Elasticsearch did not work for me, and I had to modify the onioningestor/databases/elasticsearch.py module. The old connection string is commented out, and the new connection string is below. Note that the authentication to the Elasticsearch server relies on an API key, which you’ll need to generate on the server ²⁵ ²⁵https://www.elastic.co/guide/en/kibana/current/api-keys.html.

Listing 13 onioningestor/databases/elasticsearch.py (extract)#

#self.es = Elasticsearch([{
#    'host':self.config['host'],
#    'port':self.config['port']}])
self.es = Elasticsearch(
        "https://127.0.0.1:9200",
        verify_certs=False,
        api_key="SlJsZE5wTUJlQl9lT29FVlVIT1g6RUxmM2VnQWlUZHUyWTAxNUVkVnA2UQ=="
        )

Now, configure the configuration file (onioningestor.yml). Below is the configuration file that has been used for the screenshots. Some operators were disabled on purpose because they prevented OnionIngestor from working correctly.

Listing 14 onioningestor.yml#

# This is an example ThreatIngestor config file with some preconfigured RSS
# sources, feeding extracted artifacts into a CSV file.

general:
        # Run forever, check feeds once an hour.
        daemon: True
        sleep: 10
        onion_validation: ([a-z2-7]{16,56}\.onion)
        blacklist: childporn,pedo
        interestingKeywords: hack,password,leak,drug,market,0-day,crypto,bitcoin,monero,account,malware,ransomware,virus,crack,porn,xxx
        save-thread: no         # Use a separate thread to save onions
        TorController:
                port: 9051
                password: "AwesomePassw0rd"

monitor:
        filename: monitoring.txt

sources:
        # A few threat intel blogs to get you started!
                - name: simple-text-file
                  module: simplefile
                  filename: onion_master_list.txt

        #    - name: hunchly
        #      module: hunchly
        #      domain: https://www.dropbox.com/sh/wdleu9o7jj1kk7v/AADq2sapbxm7rVtoLOnFJ7HHa/HiddenServices.xlsx

        #    - name: pystemon
        #      module: pystemon
        #      dirname: pystemon/alerts/

        #    - name: dark.fail
        #      module: dark.fail
        #      domain: https://dark.fail/

        #  - name: source-gist
        #    module: gist
        #    url: https://gist.github.com/search?l=Text&q=.onion

        #  - name: source-reddit
        #    module: reddit
        #    url: https://api.pushshift.io/reddit/search/comment/?subreddit=onions&limit=1000000
        #    feed_type: messy
        #
        #  - name: pastebin
        #    module: pastebin-account
        #    url: https://gist.github.com/search?l=Text&q=.onion
        #    feed_type: messy
        #
        #  - name: hunchly-report
        #    module: gmail-hunchly
        #    url: https://gist.github.com/search?l=Text&q=.onion
        #    feed_type: messy
        #
        #  - name: onionland-search
        #    module: collect-onions
        #    url: http://3bbaaaccczcbdddz.onion/discover
        #    feed_type: messy
        #
        #  - name: torch
        #    module: collect-onions
        #    url: http://xmh57jrzrnw6insl.onion
        #    feed_type: messy

operators:
   - name: simple-html
         module: html
         timeout: 300
         retries: 2
         interestingKeywords: hack,password,leak,drug,market,0-day,crypto,bitcoin,monero,account,malware,ransomware,virus,crack,porn,xxx
         socks5:
                 http: 'socks5h://127.0.0.1:9050'
                 https: 'socks5h://127.0.0.1:9050'

   - name: onionscan-go
         module: onionscan
         binpath: /home/unknown/go/bin/onionscan

#   - name: simple-screenshot
#     module: screenshot
#     screenshots_path: null

#  - name: yara-rule
#    module: yara
#    filename: categories.yar
#    base_score: 50

database_Engines:
        # Simple telegram notifier
        #  - name: telegram-notifier  # see https://core.telegram.org/bots/api#authorizing-your-bot
        #module: telegram
        #chat_id: YOUR-TELEGRAM-CHAT
        #token: YOUR-TELEGRAM-TOKEN

   - name: elasticsearch
         module: elasticsearch
         index: onion
         port : 9200
         host : 127.0.0.1

#  - name: email
#    module: send_email
#    alert: no             # Enable/disable email alerts
#    from: alert@example.com
#    to: alert@example.com
#    server: 127.0.0.1     # Address of the server (hostname or IP)
#    port: 25              # Outgoing SMTP port: 25, 587, ...
#    tls: no               # Enable/disable tls support
#    username: ''          # (optional) Username for authentication. Leave blank for no authentication.
#    password: ''          # (optional) Password for authentication. Leave blank for no authentication.
#    subject: '[onioningestor] - {subject}'
#    size-limit: 1048576   # Size limit for pastie, above it's sent as attachment

Below is an extract of the output while OnionIngestor is running, with debug logs:

(onioningestor) $ python3 -m onioningestor -c onioningestor.yml --log DEBUG
[17 Nov 2024 08:36:01] - INFO - Starting OnionScraper
[17 Nov 2024 08:36:01] - INFO - Loading config file
[17 Nov 2024 08:36:01] - DEBUG - Found database engine 'elasticsearch'
[17 Nov 2024 08:36:01] - DEBUG - Found 1 total database engines
[17 Nov 2024 08:36:01] - INFO - Creating Elasticsearch mapping
/data/venv/onioningestor/lib/python3.11/site-packages/elasticsearch/connection/http_urllib3.py:191: UserWarning: Connecting to https://127.0.0.1:9200 using SSL with verify_certs=False is insecure.
  warnings.warn(
/data/venv/onioningestor/lib/python3.11/site-packages/urllib3/connectionpool.py:979: InsecureRequestWarning: Unverified HTTPS request is being made to host '127.0.0.1'. Adding certificate verification is strongly advised. See: https://urllib3.readthedocs.io/en/latest/advanced-usage.html#ssl-warnings
  warnings.warn(
[17 Nov 2024 08:36:01] - INFO - Onions will be saved synchronously
[17 Nov 2024 08:36:01] - DEBUG - initializing operators
[17 Nov 2024 08:36:01] - DEBUG - Found operator 'simple-html'
[17 Nov 2024 08:36:01] - DEBUG - Found operator 'onionscan-go'
[17 Nov 2024 08:36:01] - DEBUG - Found 2 total operators
[17 Nov 2024 08:36:01] - INFO - Initializing simple-html
[17 Nov 2024 08:36:01] - INFO - Initializing onionscan-go
[17 Nov 2024 08:36:01] - INFO - Running forever, in a loop
[17 Nov 2024 08:36:01] - DEBUG - Initializing sources
[17 Nov 2024 08:36:01] - DEBUG - Found source 'simple-text-file'
[17 Nov 2024 08:36:01] - DEBUG - Found 1 total sources
[17 Nov 2024 08:36:01] - INFO - Running source 'simple-text-file'
[17 Nov 2024 08:36:01] - INFO - Processing found onions with operator 'simple-html'
[17 Nov 2024 08:36:01] - INFO - http://sq542reyqwagfkghieehykb6hh6ohku5irarrrbeeo5iyozdbhe5n3id.onion
[17 Nov 2024 08:36:08] - INFO - Processing found onions with operator 'onionscan-go'
[17 Nov 2024 08:36:08] - INFO - [*] Running onionscan on sq542reyqwagfkghieehykb6hh6ohku5irarrrbeeo5iyozdbhe5n3id.onion
[17 Nov 2024 08:37:00] - DEBUG - crawling queue added: eo5iyozdbhe5n3id.onion
[17 Nov 2024 08:37:00] - DEBUG - Saving to database
[17 Nov 2024 08:37:00] - DEBUG - elasticsearch: saving pastie[sq542reyqwagfkghieehykb6hh6ohku5irarrrbeeo5iyozdbhe5n3id.onion]
/data/venv/onioningestor/lib/python3.11/site-packages/urllib3/connectionpool.py:979: InsecureRequestWarning: Unverified HTTPS request is being made to host '127.0.0.1'. Adding certificate verification is strongly advised. See: https://urllib3.readthedocs.io/en/latest/advanced-usage.html#ssl-warnings
  warnings.warn(
/data/venv/onioningestor/lib/python3.11/site-packages/urllib3/connectionpool.py:979: InsecureRequestWarning: Unverified HTTPS request is being made to host '127.0.0.1'. Adding certificate verification is strongly advised. See: https://urllib3.readthedocs.io/en/latest/advanced-usage.html#ssl-warnings
  warnings.warn(
/data/venv/onioningestor/lib/python3.11/site-packages/urllib3/connectionpool.py:979: InsecureRequestWarning: Unverified HTTPS request is being made to host '127.0.0.1'. Adding certificate verification is strongly advised. See: https://urllib3.readthedocs.io/en/latest/advanced-usage.html#ssl-warnings
  warnings.warn(
[17 Nov 2024 08:37:01] - ERROR - {'count': 1, '_shards': {'total': 2, 'successful': 2, 'skipped': 0, 'failed': 0}}
[17 Nov 2024 08:37:01] - DEBUG - elasticsearch: pastie[sq542reyqwagfkghieehykb6hh6ohku5irarrrbeeo5iyozdbhe5n3id.onion] saved in 0.33337998390197754s
[17 Nov 2024 08:37:01] - INFO - Processing found onions with operator 'simple-html'
[17 Nov 2024 08:37:01] - INFO - http://darkfailenbsdla5mal2mxn2uz66od5vtzd5qozslagrfzachha3f3id.onion
[17 Nov 2024 08:37:05] - DEBUG - crawling queue added: incognito75yd2w2qylg7xadz2rd7o2peqt5gcvmd2irxqbqj7c6exid.onion
[17 Nov 2024 08:37:05] - DEBUG - crawling queue added: pornhubvybmsymdol4iibwgwtkpwmeyd6luq2gxajgjzfjvotyt5zhyd.onion
[17 Nov 2024 08:37:05] - DEBUG - crawling queue added: wmj5kiic7b6kjplpbvwadnht2nh2qnkbnqtcv3dyvpqtz7ssbssftxid.onion
[REDACTED]

Here is a dashboard that can be done after several hours running the script, with a few Onion links and some keywords:

Fig. 321 Custom dashboard in Elasticsearch, using data collected by OnionIngestor.#

Using Kibana, it is also possible to use the search directly:

Fig. 322 Querying OnionIngestor logs in Elasticsearch.#

Notice that the complete HTML code of the page has been downloaded, allowing advanced searches.

Fig. 323 HTML code extract collected from a page with OnionIngestor.#

If you have enabled the OnionScan operator, additional observables are collected, like email addresses, as shown below:

Fig. 324 Email address collected by OnionIngestor.#

You can then filter Onion Services that have an email collected via OnionScan:

Fig. 325 List of email addresses collected by OnionIngestor, grouped by websites.#

Darc#

Darc ²⁶ ²⁶https://darc.jarryshaw.me/en/latest/index.html is designed as a Swiss army knife for Dark Web crawling. It collects HTTP requests and response information, such as cookies, header fields, etc. It also bundles Selenium ²⁷ ²⁷https://pypi.org/project/selenium/ to provide screenshots of web pages.

Darc supports the four darknets covered in this book (Tor, I2P, ZeroNet, and Hyphanet). The architecture diagram of Darc is shown below:

To use Darc, you’ll need docker. It is recommended that you install it following this link: https://docs.docker.com/engine/install/. Don’t install it via snap if you’re on Ubuntu.

You will need two databases: one for the task manager (to manage the list of sites to query) and one to save the results. The documentation recommends running the first one over Redis and the second one with MySQL, PostgreSQL, or SQLite, but for the sake of simplicity, I used MariaDB for both on the same host.

Because docker will need to access our database, we need to configure our MariaDB service to be accessible from the outside. In /etc/mysql/mariadb.conf.d/50-server.cnf, modify the bind-address parameter from 127.0.0.1 to 0.0.0.0. Restart the service after this change.

$ sudo sed -i "/^bind-address/s/^/#/; /#bind-address/a\bind-address = 0.0.0.0" /etc/mysql/mariadb.conf.d/50-server.cnf
$ sudo systemctl restart mariadb.service

On the host (or preferably on a remote machine), create a darc database and a darc user who will be granted all privileges to this database. Notice that we use darc@% and not darc@localhost so that the user can connect remotely. Also, create a darcweb database with the same access.

$ sudo apt install mariadb-server
$ sudo mysql_secure_installation
$ mysql -u root -p
MariaDB> create database darc;
MariaDB> create database darcweb;
MariaDB> create user 'darc'@'%' identified by 'AwesomePassw0rd';
MariaDB> grant all privileges on `darc`.* to 'darc'@'%';
MariaDB> grant all privileges on `darcweb`.* to 'darc'@'%';
MariaDB> \q

Download the docker image:

$ sudo docker pull jsnbzh/darc:latest

Verify that the image has been downloaded:

$ sudo docker images
REPOSITORY               TAG       IMAGE ID       CREATED         SIZE
jsnbzh/darc              latest    770f444e299d   3 years ago     1.8GB

Download an example ²⁸ ²⁸https://raw.githubusercontent.com/JarryShaw/darc/master/docker-compose.yml of docker-compose.yml file and adapt it to fit your needs.

Now create a /data/darc/ folder and make sure it contains:

Your modified docker-compose.yml file.
An empty extra folder.
A folder named text with the following files: clinic.txt, freenet.txt, i2p.txt, tor2web.txt, tor.txt, and zeronet.txt.
Depending on what darknet you are targeting, put some links to the appropriate files. For example, you could start by adding some onion URLs to tor.txt.

Note

By default, the docker image will start the crawler and loader services automatically when the machine starts. To prevent the services from starting automatically, set the variable restart to no instead of always in the docker-compose.yml file.

You should be all set; now run the image:

$ cd /data/darc/
$ sudo docker compose up

Fig. 327 Output extract while Darc is running.#

After a while, we start collecting files:

C4darknet#

C4darknet ²⁹ ²⁹nesg-ugr/c4darknet is a darknet crawler that can extract links and other helpful information (images, scripts, titles, words) and save it in the database. Although it was originally designed to work with I2P ³⁰ ³⁰Abellan09/i2p_crawler, it can be used for crawling resources on other darknets, and even sites on the Surface Web, provided you develop the appropriate parser (crawler/darknet/spiders/spider.py).

The architecture diagram is shown below:

Fig. 329 c4darknet architecture design.#

Install and configure MariaDB. Create a database and a user who will be granted access.

$ sudo apt install mariadb-server
$ sudo mysql_secure_installation
$ mysql -u root -p
MariaDB> create database i2p_database;
MariaDB > create user 'i2p'@'localhost' identified by 'AwesomePassw0rd';
MariaDB > grant all privileges on `i2p_database`.* to 'i2p'@'localhost';
MariaDB > \q

C4darknet has been designed for Python 3.7, which is no longer available in most distributions (e.g., Debian 12 comes with Python 3.11, and Ubuntu 24.04 comes with Python 3.12 at the time of writing). To meet this requirement, though, we will create our virtual environment with conda ³¹ ³¹https://docs.anaconda.com/working-with-conda/, that we will install via Miniconda.

$ mkdir -p ~/miniconda3
$ wget https://repo.anaconda.com/miniconda/Miniconda3-latest-Linux-x86_64.sh -O ~/miniconda3/miniconda.sh
$ bash ~/miniconda3/miniconda.sh -b -u -p ~/miniconda3
$ rm ~/miniconda3/miniconda.sh
$ source ~/miniconda3/bin/activate
$ conda init --all

Now, let’s create a Python virtual environment (created by default in ~/miniconda3/envs/) that will use Python 3.7 and install the required dependencies.

Now edit crawler/database/connection_settings.py and set the correct database connection and proxy settings. The configuration file used for the tests is shown below.

Listing 15 crawler/database/connection_settings.py#

PROVIDER = 'mysql'
HOST = 'localhost'
USERNAME = 'i2p'
PASSWORD = 'AwesomePassw0rd'
DATABASE = 'i2p_database'
PROXY = '127.0.0.1:4444'

Choose a file template (or create your own) from the data directory and change the value of the INITIAL_SEEDS parameter in crawler/settings.py.

Fig. 330 Available templates with links in c4darknet.#

Each time you run c4darknet, you should execute the below requirements from your Python virtual environment.

Let’s start by recreating and repopulating the database (it will be populated with data from the selected template associated with the INITIAL_SEEDS variable).

(c4darknet) $ mysql -u root -p -e "drop database i2p_database; create database i2p_database;"
(c4darknet) $ cd /data/c4darknet/crawler/
(c4darknet) $ python3 populate.py

Remove the old spider crawling files and logs and recreate the directories.

(c4darknet) $ rm -fr mkdir /data/c4darknet/logs && mkdir /data/c4darknet/logs
(c4darknet) $ rm -fr mkdir /data/c4darknet/crawler/darknet/spiders/{ongoing,finished}
(c4darknet) $ mkdir /data/c4darknet/crawler/darknet/spiders/{ongoing,finished}

We are now ready to start the crawling process (we will assume that I2P is already running). You can supervise the process by reading the logs in the logs directory.

(c4darknet) $ cd /data/c4darknet/crawler/
(c4darknet) $ python3 manager.py &> /dev/null

³²https://stackoverflow.com/questions/76995567/error-when-crawl-data-epollreactor-object-has-no-attribute-handlesignals

Note

Checking in the logs, the following error kept coming back when I ran the crawler:

Traceback (most recent call last):
  File "/home/unknown/miniconda3/envs/c4darknet/bin/scrapy", line 8, in <module>
        sys.exit(execute())
  File "/home/unknown/miniconda3/envs/c4darknet/lib/python3.7/site-packages/scrapy/cmdline.py", line 158, in execute
        _run_print_help(parser, _run_command, cmd, args, opts)
  File "/home/unknown/miniconda3/envs/c4darknet/lib/python3.7/site-packages/scrapy/cmdline.py", line 111, in _run_print_help
        func(*a, **kw)
  File "/home/unknown/miniconda3/envs/c4darknet/lib/python3.7/site-packages/scrapy/cmdline.py", line 166, in _run_command
        cmd.run(args, opts)
  File "/home/unknown/miniconda3/envs/c4darknet/lib/python3.7/site-packages/scrapy/commands/crawl.py", line 30, in run
        self.crawler_process.start()
  File "/home/unknown/miniconda3/envs/c4darknet/lib/python3.7/site-packages/scrapy/crawler.py", line 383, in start
        install_shutdown_handlers(self._signal_shutdown)
  File "/home/unknown/miniconda3/envs/c4darknet/lib/python3.7/site-packages/scrapy/utils/ossignal.py", line 19, in install_shutdown_handlers
        reactor._handleSignals()
AttributeError: 'EPollReactor' object has no attribute '_handleSignals'

After searching on the Internet, I found a fix ³² ³²https://stackoverflow.com/questions/76995567/error-when-crawl-data-epollreactor-object-has-no-attribute-handlesignals. The error is related to the Twisted package, one of Scrapy’s dependencies. Installing a previous version of Twisted worked for me.

(c4darknet) $ pip install Twisted==22.10.0

Below is an extract of my darknetcrawler.log file at runtime. It shows the current URL being parsed, the number of ongoing threads, the finished ones, the ones with errors, the ones being discovered, etc.

$ tail /data/c4darknet/logs/darknetcrawler.log
2024-11-20 07:26:24,289 DEBUG - MainThread - mod: manager, method: check_crawling_status, msg: Files in finished folder #2
2024-11-20 07:26:24,292 DEBUG - MainThread - mod: manager, method: check_spiders_status, msg: There are 3 ongoing sites in db and 3 alive spider processes.
2024-11-20 07:26:24,292 DEBUG - MainThread - mod: manager, method: check_spiders_status, msg: Current alive spiders ['anlncoi2fzbsadbujidqmtji7hshfw3nrkqvbgdleepbxx3d5xra.b32.i2p', 'nvspc.i2p', 'opentracker.dg2.i2p']
2024-11-20 07:26:24,292 DEBUG - MainThread - mod: manager, method: check_spiders_status, msg: Spider/Site anlncoi2fzbsadbujidqmtji7hshfw3nrkqvbgdleepbxx3d5xra.b32.i2p is sleeping.
2024-11-20 07:26:24,292 DEBUG - MainThread - mod: manager, method: check_spiders_status, msg: Current alive spiders ['anlncoi2fzbsadbujidqmtji7hshfw3nrkqvbgdleepbxx3d5xra.b32.i2p', 'nvspc.i2p', 'opentracker.dg2.i2p']
2024-11-20 07:26:24,292 DEBUG - MainThread - mod: manager, method: check_spiders_status, msg: Spider/Site nvspc.i2p is sleeping.
2024-11-20 07:26:24,292 DEBUG - MainThread - mod: manager, method: check_spiders_status, msg: Current alive spiders ['anlncoi2fzbsadbujidqmtji7hshfw3nrkqvbgdleepbxx3d5xra.b32.i2p', 'nvspc.i2p', 'opentracker.dg2.i2p']
2024-11-20 07:26:24,293 DEBUG - MainThread - mod: manager, method: check_spiders_status, msg: Spider/Site opentracker.dg2.i2p is running.
2024-11-20 07:26:24,293 DEBUG - MainThread - mod: manager, method: get_sites_from_floodfill, msg: There are 0 floodfill sites.
2024-11-20 07:26:24,307 DEBUG - MainThread - mod: manager, method: main, msg: Stats --> ONGOING 3, PENDING 0, FINISHED 2, ERROR 0, ERROR_DEFUNC 0, DISCOVERING 54, DISCARDED 0

The ongoing and finished directories are populated shortly after you start the crawling process, as shown below.

$ tree /data/c4darknet/crawler/darknet/spiders
.
├── finished
│   ├── hq.postman.i2p.json
│   ├── pizdabol.i2p.fail
│   └── tracker2.postman.i2p.json
├── __init__.py
├── ongoing
│   ├── anlncoi2fzbsadbujidqmtji7hshfw3nrkqvbgdleepbxx3d5xra.b32.i2p.json
│   ├── nvl_2sr27o5x2v2pyqro7wl5nl6krrsbizwrzsky5y7pkohwh24gn6xq.b32.i2p.txt
│   ├── nvl_333.i2p.txt
│   ├── nvl_5hkhjehj3ct2pvcah7dcylwef2oti3xij5myxbv3pd7rocio5vkq.b32.i2p.txt
│   ├── nvl_5iedafy32swqq4t2wcmjb4fvg3onscng7ct7wb237jkvrclaftla.b32.i2p.txt
│   ├── nvl_5vik2232yfwyltuwzq7ht2yocla46q76ioacin2bfofgy63hz6wa.b32.i2p.txt
│   ├── nvl_animal.i2p.txt
│   ├── nvl_anlncoi2fzbsadbujidqmtji7hshfw3nrkqvbgdleepbxx3d5xra.b32.i2p.txt
│   ├── nvl_bnb46culzbssz6aipcjkuytanflz6dtndyhmlaxn3pfiv6zqrohq.b32.i2p.txt
│   ├── nvl_csen43keji3qiw6uobsgzysxyjd225g6446ylq5uuz6ur2glkzaa.b32.i2p.txt
│   ├── nvl_ctvfe2fimcsdfxmzmd42brnbf7ceenwrbroyjx3wzah5eudjyyza.b32.i2p.txt
│   ├── nvl_i2p-projekt.i2p.txt
│   ├── nvl_identiguy.i2p.txt
│   ├── nvl_neodome.i2p.txt
│   ├── nvl_nvspc.i2p.txt
│   ├── nvl_ol.i2p.txt
│   ├── nvl_omt56v4jxa4hurbwk44vqbbcwn3eavuynyc24c25cy7grucjh24q.b32.i2p.txt
│   ├── nvl_opentracker.dg2.i2p.txt
│   ├── nvl_paste.r4sas.i2p.txt
│   ├── nvl_pizdabol.i2p.txt
│   ├── nvl_pomoyka.i2p.txt
│   ├── nvl_pravtor.i2p.txt
│   ├── nvl_syndie-project.i2p.txt
│   ├── nvl_w7tpbzncbcocrqtwwm3nezhnnsw4ozadvi2hmvzdhrqzfxfum7wa.b32.i2p.txt
│   ├── nvspc.i2p.json
│   ├── pizdabol.i2p.json
│   ├── pomoyka.i2p.json
│   └── pravtor.i2p.json
├── __pycache__
│   ├── __init__.cpython-37.pyc
│   ├── spiderBase.cpython-37.pyc
│   └── spider.cpython-37.pyc
├── spiderBase.py
└── spider.py

4 directories, 37 files

The output is a JSON file that looks like the one below. Notice that this is also available in the sitehomeinfo table from the database.

$ cat hq.postman.i2p.json | python3 -m json.tool
{
        "darksite": "hq.postman.i2p",
        "language": {
                "GOOGLE": "",
                "NLTK": "english"
        },
        "extracted_darksites": [],
        "total_darksite_pages": 1,
        "title": [
                "Postman HQ | Blocked Request"
        ],
        "size_main_page": {
                "WORDS": 70,
                "LETTERS": 303,
                "IMAGES": 0,
                "SCRIPTS": 0
        },
        "main_page_tokenized_words": [
                ":root{",
                "--border_table:inset",
                "0",
                "0",
                "0",
                "1px",
                "rgba(255,255,255,.3),inset",
                "0",
                "0",
                [REDACTED]
                "#86c3f9;",
                "xmlns='http://www.w3.org/2000/svg'",
                "viewBox='0",
                [REDACTED]
                [REDACTED]
                "settings.If",
                "so,",
                "please",
                "contactpostman@mail.i2pby",
                "mail",
                "or",
                "on",
                "IRC2P."
        ]
}

Summary Table#

The previous sections introduced some of the crawlers available for different darknets. The table below shows which ones you can use to monitor the four darknets detailed in this book.

⁴³c4darknet may be able to connect to other darknets, but you will need to develop specific spiders, that are not available out of the box.

	Tor	I2P	Hyphanet	ZeroNet
TorBot
TorCrawl
VigilantOnion
OnionScan
OnionIngestor
Darc
c4darknet ⁴³ ⁴³c4darknet may be able to connect to other darknets, but you will need to develop specific spiders, that are not available out of the box.
AIL framework
Bathyscaphe Dark Web crawler
Dark Scrape
Darkdump
DarkWeb Crawler and Indexer
Darklight
Onionstack
Darkus
Midnight Sea
Prying Deep

Reporting#

Having a clear objective from the very beginning of your project will be key. This will tell you what information needs to be stored in your database and how it should be organized. Below are some possible options.

Alert rules: You may want to schedule a task that will search for some criteria and alert you in case of a match. This can also be done during the crawling. You may, for example, want to monitor any reference to a list of domains, your company name, email addresses, etc.
Index: An index is a list of links you can organize by categories (e.g., books, games, blogs, etc.).
Search engine: You may want to develop a search engine where users will search for matching terms in your database. These terms may be searched based on a predefined list of possible criteria, in page titles, or on full-page indexing (provided that all content is indexed in your database).
Dashboards based on observables: most likely to do statistics for a paper or a book or to track changes or evolution over time. Observables include email addresses, credit card information, social security numbers, postal addresses, PGP keys, crypto addresses, passwords, file hashes, etc.

In addition to the open-source projects referenced in the previous sections, you can also consider the ones below, more specifically for reporting purposes:

Create a Search Engine	⁴⁴AshwinAmbal/DarkWeb-Crawling-Indexing DarkWeb Crawler and Indexer ⁴⁴ ⁴⁴AshwinAmbal/DarkWeb-Crawling-Indexing: Crawls Onion Services and indexes results in an Apache Solr database. Features a search engine. ⁴⁵vlall/Darksearch Darksearch ⁴⁵ ⁴⁵vlall/Darksearch: Query cached Onion sites, IRC chatrooms, various PDFs, game chats, blackhat forums, etc. ⁴⁶scresh/Digamma Digamma ⁴⁶ ⁴⁶scresh/Digamma: Real time search engine for Tor sites and IoT devices.
Graphical organization of collected data	⁴⁷saidortiz/onion_osint Onion OSINT ⁴⁷ ⁴⁷saidortiz/onion_osint: Relies on the “networkx” Python library to build a map of IP addresses collected during the crawling process. ⁴⁸ntddk/onionstack onionstack ⁴⁸ ⁴⁸ntddk/onionstack: Creates a pictorial book of collected Onion Services.
Monitor the health of Onion Services	⁴⁹k4m4/onioff ONIOFF ⁴⁹ ⁴⁹k4m4/onioff: Checks the status of a list of Onion Services. ⁵⁰reidjs/onionup OnionUp ⁵⁰ ⁵⁰reidjs/onionup: Tracks the response time of a list of web pages (Surface Web) or Onion Services (Tor) on a time chart graph. ⁵¹desyncr/onionuptime Hidden Service Uptime ⁵¹ ⁵¹desyncr/onionuptime: Shows the response time on a time chart graph and computes the service availability percentage of a list of Onion Services.

Chapter 7: Intelligence and Hunting on the Dark Web

Contents

Chapter 7: Intelligence and Hunting on the Dark Web#

Introduction#

Why Does Monitoring the Dark Web Matter?#

Definition of the Scope#

Steps for a Successful Monitoring#

Sources Collection#

Link Directories#

Monitor the Links#

Extracting Information#

Torsocks, Torify, and Proxychains#

TorBot#

TorCrawl#

VigilantOnion#

OnionScan (Prerequisite for OnionIngestor)#

OnionIngestor#

Darc#

C4darknet#

Other Resources#

Summary Table#

Reporting#

Challenges of Automated Intelligence#

DDoS and Bots Protections#

Registration Process#

Required Established Reputation#

Invite-Only Forums or Markets#

Evidence of Activity#

Language#

Other Challenges#

Commercial vs Open-Source Solutions#
